PLX7200 Medical Mobile 3D Digital Radiology Equipment X-Ray C-Arm System (Cone Beam CT)

PLX7200 Medical Mobile 3D Digital Radiology Equipment X-Ray C-Arm System (Cone Beam CT) widely used in Orthopedics, general surgery, othopedic surgery, urology, spinal surgery, abdominal surgery, gastroenterology department, gynecology and operating room etc. Bone tissue biopsy, spine pedicle screw implantation, long tubal bone marrow nail fixation and hand, foot fracture surgery with screw fixation.
Get a Quete

PLX7200 Medical Mobile 3D Digital Radiology Equipment X-Ray C-Arm System (Cone Beam CT)

PLX7200 Medical Mobile 3D Digital Radiology Equipment X-Ray C-Arm System (Cone Beam CT)  widely used in Orthopedics, general surgery, othopedic surgery, urology, spinal surgery, abdominal surgery, gastroenterology department, gynecology and operating room etc. Bone tissue biopsy, spine pedicle screw implantation, long tubal bone marrow nail fixation and hand, foot fracture surgery with screw fixation.

Isocentric Design Technology:

Eliminate the need for repositioning and enable both and dose saving Ensure a constant image size with varying projections Wide orbital rotation of up to 190° Prerequisite for 3D imaging via orbital movement

Category

Item

Main Contents

Electrical Performance

X-ray Generator

Output Power: 5.0kW    Inverter Frequency: 60kHz

Continuous Fluoroscopy

(Automatic/ Manual)

Tube Voltage: 40kV~125kV    continuous adjustment


Tube Current:0.3mA~4mA     continuous adjustment

Pulse Fluoroscopy

Tube Voltage:40kV~125kV     continuous adjustment

Tube Current:4.1mA~30mA     continuous adjustment

Pulse Frequency:1-10 frame/  continuous adjustment

C-arm Rotation Sequences Radiography

Tube Voltage:40kV~125kV      continuous adjustment

Tube Current:4.1mA~15mA      continuous adjustment

Number of Sequence Radiography: 100frame

Radiography

40kV~125kV  100mA   0.01-180mAs

X-ray Tube

Rotary Anode Focus

0.3/1.5mm

Anode Thermal Capacity

35kJ

Tube Thermal Capacity

650kJ

Image System

Image Intensifier

TOSHIBA 9" image intensifier

CCD Camera

Medical Mega-pixels digital CCD camera

Monitor

19′ MEGA pixels high definition Medical LCD Monitor

Digital Image Processing System

Image acquisition module:

Achieve a single frame, sequence image acquisition, ultra-high-speed Ethernet pass – real-time transmission


The image processing module:

Images have been collected or stored in the module of image processing: tagging, zoom, measurement, sub- window display, Continuous play. 90 Rotation , horizontal mirror , vertical mirror function


The report module:

Modify report templates provide a variety of content, user-friendly report writing, report printing function


Film print module:

Follow Dicom Medical film typesetting and printing capabilities


Image 3D Processing:

1) Sequence image reconstruction: Run 3D image reconstruction after the acquisition of sequence data is complete.

2) Image reconstruction time less than 10s.

3) Automatic display of the Cross plane, Coronal plane, Sagittal plane and 3D image

4) 3D display: MIP and VRT

Structure Performance

Direction Wheel

Main Wheel

Direction wheel 360°rotation

Main wheel ±90°rotation

C-arm

Motorized rotation around horizontal axis: ±180°


Motorized slip on orbit: 190°


Rotation around vertical axis: ±15


Motorized forward and backward movement: 200mm


Motorized ascending and descending of pillar: 400mm


SID:1025 mm   Open:825 mm    Arc depth:810 mm
