Physical characteristics:
Main unit: Portable
Dimensions:L320xW205xH410
Weight:9.8kg
Technical specifications:
(1)Defibrillator type Manual, Synchronized, Asynchronized
(2)Energy accuracy  +1%
(3)Energy selection: 0, 3, 5, 7, 10, 20, 30, 50, 100, 200, 300, 360 joules (nominal at a resistance of 50)
(4)Charging time: Maximum 10 seconds to 360 Joules
(5)Standard Adult/Pediatric Paddles: Reusable external adult paddles (pediatric paddles integrated)
Power requirements
(a)AC Power supply 100V~240V,50Hz/60 Hz
(b)Vehicle Voltage(Option)   DC 12V
Internal Battery Backup
(1)Battery type: Rechargeable lead-acid battery (12V 2.0Ah  X2)
(2)Charging time: Time-Minimum of 4 hours for full charging
(3)Battery charging: During AC Power Supply operation of the device
(4)Charging /Low Battery Indication: Red LED
(5)Battery Capacity: 100% of the battery will provide 120-min monitoring; and 35 discharges at 360 joules.
Display
-LCD Dimensions 7-inch
-Type High resolution true-color: graphic
-Resolution 480X234
ECG
ECG lead: AVR, AVL, AVF, V1~V6
Protection: With stand 4000vAc/50Hz voltage in isolation and work against electrosurgical knife and defibrillation
Respiration
Measurement method: Thoracic impedance
NIBP
Working mode: Manual/Automatic/stat(5 minutes)
Method: Automatic oscillation
Cuff type: standard Adult; optional Pediatric/Neonatal
Temperature
Measurement range 20~45℃
Resolution 0.1
Pulse Oximetry(spO2)
Display :spo2 value, pulse histogram, waveform, Pulse
Range: 0~99%for adult, pediatric and neonatal patients
Probe :standard adult finger clip
optional pediatric Y-type clip and neonatal wrap
Pulse range
Pulse range: 0-255bpm
Standard parameter & configuration
ECG/ RESP/SPO2/TEMP/PR/NIBP/DEFIBRILLATOR
Optional
Recorder, Li-ion battery (11.1V 4Ah  X2)
