Engineered for increasingly complex surgical scenes, AOT500 comes with intelligent automatic control system satisfying various demands of general surgeries.
1.Rational base design provides an active space for medical staffs’ feet.;
2.The table has five parts: head board, back board, kidney elevator, hip board and leg board.
3.leg part imported gas easy control;
3. Adopts full 304 stainless steel;
Hospital Operating Table Electric Column For General Surgery Description:
The operating table electric column provides more maneuverability. The hospital operating table widely used in a variety of surgical positioning. Electric Operating Table's extensive selection of accessories makes it suitable for almost all types of surgery.
The table is recommended for various types of operations, especially general operations and orthopedic treatment with appropriate accessories. The operating table can also be used for special patient positioning during surgery, so that surgeons can have good access to the surgical site.
Hospital Operating Table Electric Column Features:
General features:
1. Accessories, guide rail, bottom shell, column shell are made of stainless steel. The use of stainless steel materials reducing the amount of pollutants generated on the table surface.
2. The table surface is divided into 5 parts: head section, back section, buttocks section, and two detachable leg sections.
3. Super wide desktop, the board can shift longitudinally. It can be X-rayed or scan when using along with C-arm .
4. The leg board is dismantlable. It is manual rotation and convenient for urology surgery.
5. The memory pad antistatic ,waterproof design to ensure the comfort of the operation.
6. Equipped with large casters, this operating table can be transferred regardless of the terrain.
7. Extreme weight load capacity of 250kgs with highest safety and stability.
Electrical characteristics:
1. The operating table adopts high quality electrical system, high degree of automation, low noise, strong reliability, safe and reliable.
2. Equipped with automatic charging device and battery to ensure normal operation of the operating table in case of emergency power failure. Battery power for 50-80 operations.
Technical features:
1. Two control modes
-The manual controller provides all the features that are needed for maximum convenience and availability of the choice. One-click reset function.
-The product has additional control options. All movements can be smoothly and accurately controlled on the operating table through the control panel on the side of the bed, thus providing employees with a more efficient and flexible working mode.
-Hand controller can be optional LCD display.
2. A wide range of lifting space 710-1110mm, providing doctors with more operational.
3. Version with 12cm large wheel and "H" base to ensure high stability and high table mobility.
4. The double-joint head plate of this electrical operating table can freely adjust the height of the headboard, allowing the patient to have a comfortable head angle when performing operations in different positions.
5. The vertical translation of the table up to 350mm and the asymmetric position of the column allow the use of the C-arm during intraoperative patient monitoring.
Main Parameter | |
Model | AOT500 |
Operating Table Size | |
Length | ≥2100mm |
Width | ≥550mm |
Table Overall Adjustable Range | |
Min. height of table top from floor | 710mm |
Max. height of table top from floor | 1110mm |
Tendelenburg | ≥25º |
Reversed tendelenburg | ≥25º |
Lateral tilt | ≥15º |
Backward and forward movements | 350mm |
Table Section Adjustment Range | |
Head section raised from the horizontal | ≥40º |
Head section lowered from the horizontal | ≥90º |
Kidney bridge elevated | 110mm |
Back section raised from the horizontal | ≥80º |
Back section lowered from the horizontal | ≥15º |
Leg section raised from the horizontal | ≥15º |
Leg section lowered from the horizontal | ≥90º |
Foot board can be horizontal or vertical with leg board. | |
Power Supply | AC 220V±10%,50Hz |
Basic Accessories: | Anaesthetic screen: 1 set |
Arm support: 1 pair | |
Body support: 1 pair | |
leg support: 1 pair | |
Cushion: 1 set |
